- Used under rough conditions for grinding of hard, medium-hard, brittle and tough materials
- Required few minutes to achieve the desired grind size, and work continuously
- Application examples: minerals, ores, bauxite, clinkers, chalk, chamotte, concrete, construction materials, soil samples, gypsum … etc.
Small Disc Model:
- Capacity: 20 – 100 kg/hr depending on material and final size
- Disc diameter: 170 mm
- Feeding size: < 10 mm
- Final fineness: 50 – 200 microns
- Collector: 25 x 20 x 8 cm
- 380V/50Hz
Large Disc Model:
- Capacity: 40 – 200 kg/hr depending on material and final size
- Disc diameter: 205 mm
- Feeding size: < 15 mm
- Final fineness: 50 – 200 microns
- Collector: 25 x 20 x 8 cm
- 380 V / 50 Hz
- MS 0111-1: Disc Mill Small or Large
- MS 0111-2: Spare Discs
